Measurement Range: 1 x 10-4 - 1000 Torr (for N2) Absolute
Set Point Range: 1 x 10-4 - 1000 Torr, Absolute
Fitting Type: 0.25 in VCR female
Interface: DeviceNet
Connector: 15-pin, high density D-sub male
Operating Temperature; 0 - 40°C (32° to 104°F) ambient, non-condensing
Storage Temperature: -40 - 85°C (-40 - 185°F)
Relays: 4
Relay Contact Rating: 1 Amp @ 30 VDC resistive, or AC non-inductive
Exposed Materials: 304 stainless steel, borosilicate glass, Kovar®, alumina, NiFe alloy, polyimide, pyrex, ceramic, silicon, epoxy, RTV, Viton®, and nickel
Case Material: Aluminum extrusion with powder coat
Internal Volume: 35 cm3 (2.14 in3)
Units: Torr
Display: 3 digit green LED, automatic ranging
Differential Pressure Measurement Range: 750 Torr below Atmosphere to 250 Torr above Atmosphere
Differential Pressure Set Point Range: 750 Torr below Atmosphere to 125 Torr above Atmosphere
Differential Pressure Accuracy: ±2.5 Torr +2.5% of Reading
DeviceNet Version: ASCII format
DeviceNet Baud Rates: 125k, 250k, 500k (Default) switch selectable
DeviceNet Address: 0-63 (63 default) switch selectable
