MKS 221B Baratron® ເຄື່ອງປ່ຽນຄວາມດັນຕ່າງກັນ Bakeable (10 Torr; 0.5 in. Tube)
Full Scale Range: 10 Torr
Fitting Type: 0.5 in. OD tube
Accuracy: 0.5% of Reading (± temperature coefficients)
Resolution: 0.01% of Full Scale
Analog Output: 0 - 10 VDC
Electrical Connector: AMP 14-pin ribbon
Zero Temperature Coefficient: 0.02% of Full Scale/°C
Span Temperature Coefficient: 0.04% of Reading/°C
Operating Temperature Range: Sensor: 0 - 150°C (bakeable to 200°C with cable removed), Preamp: 0 - 50°C
Exposed Materials: Px side: Inconel
Pr side: Inconel, Ceramic, Palladium, Stainless Steel, Glass
Volume: Px side: 7.9 cc
Pr side: 19.0 cc
Overpressure Limit: 140 kPa
Power Requirements: ±15 VDC
For specific range please check the attachment below!
