X/Y-axis Travel: 400x400
Z-axis Travel: 200mm
X/Y/Z Linear Scale: Resolution：0.1mm µm
Guidance Mode: High-precision P-grade Double-Track Linear Guide
Operation Mode: Joystick controller, Mouse operation, automatic detection program
Probe System: Renishaw MCP Probe change system (Optional)
Measurement Accuracy: XY-axis：2+L/200(um) / Z-axis：3.5+L/100(um)
Repeatability: ±1.5um
Video System: 1/2" Color CCD Camera / 6.5X Automatic Zoom Lens / Optical Magnification：0.7X-4.5X， Video Magnification：20X~190X
Illumination
Contour：LED Parallel Contour Illumination
Surface：5-ring 8-division 0~256 grade continue adjustable
Working Environment
Temperature：20℃±2℃，Temperature Change＜2℃/hr，
Humidity：30％－80％RH，Vibration＜0.002g, <15HZ
Measuring Software: Mikrosize
Load Capacity: 30Kg
Power Supply: AC110V/60Hz; 220V/50Hz
Machine Dimension(L×W×H): 1240*948*1650
Package Size (L×W×H): 1550*1080*1800mm
Instrument Weight: 580
Standard Delivery:
Mainframe with Optical Glass: Grade 00 Natural Marble: 1
Moving Control System with Joystick: UWC3500i: 1
Linear Scale: Imported Renishaw Reflective Linear Scale: 3
Linear Guide: HIWIN: 3
ball screw: Taiwang TBI grinding grade ball screw: 3
Motor: Panasonic: 3
Camera: 1/2”CCD Colorful High resolution: 1
Zoom Lens: Fully auto Zoom Lens: 1
Surface Illumination: Programmable 5-ring 8-division LED surface illumination: 1
Calibration Board: Company customization: 1
Computer: DELL: 1
Sofwtare: INS-C: 1
