Turret: auto
Built-in Mini Printer: Yes
Data Statistic Function: Yes
Objective: 10X(Observe&Measure), 40X(Observe&Measure)
Eyepiece: 10X digital eyepiece with built-in encoder
Total Magnification: 100X(Observe&Measure), 400X(Observe&Measure)
Test Force: 10gf (0.098N)、25gf (0.245N)、50gf (0.49N)、100gf (0.98N)、 200gf (1.96N)、300gf (2.94N)、500gf(4.9N)、1000gf (9.8N)
Hardness Scale: HV0.01, HV0.025, HV0.05, HV0.1, HV0.2, HV0.3, HV0.5, HV1
Conversion Scale: HRA, HRB, HRC, HRD, HRF, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T,HV, HK, HBW
Loading Speed: ≤50μm/sec
Indentor: Standard Rectangular Pyramid Diamond Indenter (136º±0.5º)
Objective lens center and indenter center: Coincidence accuracy error< 1um (objective lens center position can be adjusted)
Measurement Resolution: 0.01µm
Data Display /Output: 8 "Touch Screen Display, Can Store 20 Test Results, USB drive, Built-in Printer and RS-232 Interface
Hardness Test Range: 8~2900HV
Loading Method: Automatic （loading、dwell、unloading）
Dwell Time: 1-99s(each step is 1 second)
Test Space
Test height: 100mm (Vertical); Test Throat: 130mm(Horizontal)
X-Y Test Anvil: Dimension：100*100mm, Movement:25*25mm, Moving Resolution Ratio:0.01mm
Illumination: LED Cold light source (can be continuous use for 24 hours, no heat generate ensure stable working, servicing life can reach 100,000 hours)
Machine Size&N/W: 540*260*650mm,50kg
Package Size&G/W: 710*420*627mm ,68kg
Power supply: AC220V+5%，50-60Hz(110V is available)
Executive Standards: GB/T4340, ASTM E384 & E92, EN-ISO 6507, JIS B-7734
Packing List
Weight Shaft: 1pc
Eyepiece: 1 pc
X-Y Test Anvil: 1 pc
Gradienter: 1 pc
Power Cord: 1 pc
Product Certificate, Warranty Card: Each 1 Copy
Printing Paper: 1 pc
Screwdriver: 2 pc
Item: Quantity
Weight: 6 pcs
Micro Hardness block: Each 1 pc
Spare Fuse (2A): 2 pcs
Dust Cover: 1 pc
Instruction Manual: 1 pc
Touch Pen: 1 pc
Level adjustment screw: 4 pcs
