Test Frequency:20Hz~200kHz
Points Of Test Frequency: Continuity
Basic Accuracy: ± 0.1%
AC Drive Level: 10mV to 2Vrms (1m Vrms solution)
DC Drive Level: 0.01V-2V
Output Impedance: 100Ω
Frequency trimming resolution: 5 Digits
Frequency output accuracy: ±0.01%
AC test speed Max.: 75mS
DC test speed (Max.):30mS
DC Bias Current Source:Option (Model 6220)
Measured Value Detection Mode:Define upper and lower thresholds according to main and sub parameters
ESR:Series/Parallel
Mathematical Mode:Absolute/Percentage
Test Range:Automatic/Lock
Indicator:Pass/Fail and Built-in speaker
Safety:EN61010-1
Immunity:EN61326-1
Emissions:EN55022 Class A
Calibration:Open Circuit / Short Circuit: Avoid the misreading caused by the stray capacitance from kelvin clips and fixtures
Auto-save when power-off function:When the power is turned off or encounter a power outage, all the data will be saved automatically and recovered when tester system is switched on again
Power Supply:Voltage 90-132Vac or 198-264Vac (selectable)
Frequency: 47 ~ 63Hz
Display800*480 Color Screen, 7" TFT
Interface:RS-232, GPIB, Handler, USB
Flash Memory:Built-in flash for storage of 64 groups of Multi-steps setting (Each group contains up to 30 steps)
Operation:Auto、Manual、RS-232、GPIB、Handler
Temperature : 10°C to 40°C
Humidity : 20 ~ 90%
Dimension (W*H*D):337x145x522 mm
Weight:6.5Kg
Standard Accessories
Power Cord,User Manual,BNC Kelvin Clips (F423901),BNC Kelvin Clips (F423501)
Optional Accessories
Meter Link Software, RS-232cable,Handler Box,SMD Fixture Box (F423905),DIP Fixture Box (F423503)
