6266 Transformer Tester
- Measurement parameters: Turn Ratio, Phase, L, Q, Leakage L, Balance, ACR, Cp, D, X, Y, DCR, Pin-Short
- Parameters measurement ranges
+ L, LK: 0. 1nH~9999.99H
+ C: 0.00001pF~999.99mF
+ Q, D: 0.00001 ~ 99999
+ Z, X, R: 0.00001Ω ~ 99.9999MΩ
+ Y: 0.01nS ~ 99.9999S
+ θ: -180°~ +180°
+ DCR: 0.01mΩ ~ 99.999MΩ
+ Turn Ratio: 0.01 ~ 99999.99turns
+ Pin-Short: 12 pairs, between pin to pin
- Built-in storage: testing files 128 sets
- Interface: RS-232, Handler, LAN, USB Host, EXT. I/O
- Power supply: Voltage 90Vac-125Vac or 190Vac-250Vac
Frequency: 47Hz-63Hz
- Max. frequency: 500kHz
- Display: 800*480 Color Screen, 7" TFT
- Dimension (W*H*D): 435x145x522 mm
- Weight: 9kg
7721 Impulse Winding Tester
- Channel: 21
- Impulse voltage (Programmable): 200-5000V
- Test items: Total area, area size comparison, Waveform comparison, Flutter, Corona
- Built-in Storage: 200 sets testing waveform
- Interface: RS-232, Remote, Printer
- Power supply: Voltage 115/230Vac ±15%
Frequency 50/60Hz ± 5%
- Display: 320*240, 5.7" dot-matrix
- Dimension (W*H*D): 435x190x522 mm
- Weight: 16 kg
7605 Hipot tester
- Channel: 2
- Measurement item: AC / DC / IR
+ Output voltage: 100V-5000V / 10V-6000V / 10-1000Vdc
+ Resolution: 1V / 1V / 1V
+ Accuracy: ±(3% of setting+5V) / ±(3% of setting+5V / ±(3% of setting+5V)
+ AC upper threshold: 0.001-31mA / 0.001-11mA / 1-12000MΩ
+ AC arcing detection: 1-20 / 1-10 / -
- Built-in storage: 30 sets setting files
- Interface: RS-232, Remote, USB Host/Device, EXT. I/O
- Power supply: Voltage 90Vac-264Vac
Frequency 50/60Hz±5%
- Display: 480*272, 4.3" TFT LCD
- Dimension (W*H*D): 365x145x430 mm
- Weight: 14 kg
Standard accessories
Power Cord
User Manual(CD)
Scan Box (F7721)
HV Test Cable
25Pin-25Pin cable
Remote Control Cable
24V Switch Power Supplier
Optional accessories
PC Link Software
RS-232 cable
Dual Scan Box (F7721-D)
