Microchip Technology PIC18F14Q40-E/P ມາຄຣອຄຄອນໂຕເລີ 16KB Flash, 1K RAM, 512 EEPROM, 12b ADCC, 8b DAC, DMA, 16-bit PWM, PPS, UART, SPI/I2C

Core: RISC

Width: 7.87 mm

Length: 26.16 mm

Data RAM Size: 1 kB

Data RAM Type: SRAM

Data ROM Size: 512 B

Data ROM Type: EEPROM

ADC Resolution: 12 bit

DAC Resolution: 8 bit

Data Bus Width: 8 bit

Interface Type: I2C, SPI, USART

Mounting Style: Through Hole

Number of I/Os: 18 I/O

Watchdog Timers: Watchdog Timer, Windowed

Processor Series: PIC18F

Program Memory Size: 16 kB

Program Memory Type: Flash

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 1.8 V

Number of ADC Channels: 17 Channel

Maximum Clock Frequency: 64 MHz

Number of Timers/Counters: 5 Timer

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C
