Microchip Technology MCP6471T-E/LTY ເອັັບພລິຟາຍເລີຍປະກອບການດໍາເນີນງານ ເອັັບພລິຟາຍເລີຍດຽວ 2 MHz OP E temp

Shutdown: No Shutdown

Topology: Single

Input Type: Rail-to-Rail

Output Type: Rail-to-Rail

Unit Weight: 6 mg

Qualification: AEC-Q100

Amplifier Type: Linear Op Amp

Mounting Style: SMD/SMT

SR - Slew Rate: 1.1 V/us

Number of Channels: 1 Channel

Supply Voltage - Max: 5.5 V

Supply Voltage - Min: 2 V

Ib - Input Bias Current: 150 pA

Operating Supply Current: 100 uA

Vcm - Common Mode Voltage: 0 V to 5.8 V

Ios - Input Offset Current: 100 fA

Output Current per Channel: 10 mA

Vos - Input Offset Voltage: 1.5 mV

GBP - Gain Bandwidth Product: 2 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

In - Input Noise Current Density: 0.6 fA/sqrt Hz

en - Input Voltage Noise Density: 27 nV/sqrt Hz

CMRR - Common Mode Rejection Ratio: 83 dB

PSRR - Power Supply Rejection Ratio: 91 dB
