Shutdown: Shutdown
Input Type: Differential
Resolution: 14 bit
Architecture: SAR
Qualification: AEC-Q100
Sampling Rate: 500 kS/s
Interface Type: SPI
Mounting Style: SMD/SMT
Reference Type: External
Power Consumption: 1.8 mW
Reference Voltage: 5.1 V
Number of Channels: 1 Channel
Number of Converters: 1 Converter
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 1.7 V
Analog Supply Voltage: 1.8 V
Digital Supply Voltage: 1.7 V to 5.5 V
INL - Integral Nonlinearity: 0.27 LSB
SNR - Signal to Noise Ratio: 83.7 dBFS
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: 0.11 LSB
THD - Total Harmonic Distortion: - 100.9 dB
SFDR - Spurious Free Dynamic Range: 103.8 dB
SINAD - Signal to Noise and Distortion Ratio: 83.9 dBFS
