Fall Time: 10 ns
Rise Time: 11 ns
Technology: Si
Unit Weight: 14.194 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 P-Channel
Qg - Gate Charge: 7.8 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 2 W
Vgs - Gate-Source Voltage: - 10 V, + 10 V
Typical Turn-On Delay Time: 13 ns
Typical Turn-Off Delay Time: 32 ns
Id - Continuous Drain Current: 5.4 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 6 S
Rds On - Drain-Source Resistance: 60 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 900 mV
