Fall Time: 11.1 ns
Rise Time: 10.7 ns
Technology: Si
Unit Weight: 360 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N- Channel
Qg - Gate Charge: 11.8 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 83 W
Vgs - Gate-Source Voltage: - 30 V, + 30 V
Typical Turn-On Delay Time: 10.33 ns
Typical Turn-Off Delay Time: 29.1 ns
Id - Continuous Drain Current: 9 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 9.2 S
Rds On - Drain-Source Resistance: 250 mOhms
Vds - Drain-Source Breakdown Voltage: 200 V
Vgs th - Gate-Source Threshold Voltage: 1 V
