Fall Time: 12 ns
Rise Time: 8 ns
Technology: Si
Unit Weight: 87.500 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 67 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 85 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 15 ns
Typical Turn-Off Delay Time: 48 ns
Id - Continuous Drain Current: 80 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 30 S
Rds On - Drain-Source Resistance: 4.2 mOhms
Vds - Drain-Source Breakdown Voltage: 60 V
Vgs th - Gate-Source Threshold Voltage: 1.1 V
