Operation: Right angle light scatter detection, using a laser diode as light source
Measurement Resolution: 0.1μg/m3
Number of Mass Channels: 4 (PM1, PM2.5, PM4, PM10)
Data Storage Intervals: 1, 5, 10, 15, 30, or 60 minutes
Sample Air Flow Rate: 1LPM
Sheath Air Flow Rate: 1LPM
Flow Control: Active volumetric flow control
Communications Connections: RS-485, RS-232, USB, Optional CCS Modem
Operating Temperature: 0~50°C
Storage Temperature: -20~60°C
Ambient Humidity Range: 0~95%, non-condensing
User Interface: Menu-driven interface with 4x20 character OLED display and dynamic keypad
Power Supply: Universal 100~240VAC input, 50/60Hz.
Power Consumption: 12 VDC; Max operating current 1300mA
Alarm Contact Closure:
- Normally open/ normally closed contact closure relay output.
- Contact rating 1.0A at 30V DC max.
Weight: 8.5lbs without power supply, 10lbs with power supply
Dimensions: Height: 20"; Width: 8"; Depth: 6"
Communications Protocol: Terminal Command Set, Modbus 7500 Protocol
Supplied Accessories:
- External Power Cable
- USB Cable
- Weatherproof TSP inlet with debris screen
- Mounting Bracket
Optional Accessories:
- CCS Comet Cloud Modem
- AIO 2 Sonic Weather Sensor
- MSO Weather Sensor
- Tripod
- RS232 Communication Cable
- RS485 Communication Cable
