Flow range: 0.5 – 50 LPM
Accuracy: 0.5% of reading
User-selectable measurement units:
Volumetric flow: mL/min, L/min, cc/min, cf/min
Standardized flow: smL/min, sL/min, scc/min, scf/min
Temperature: °C, °F
Pressure: mmHg, PSI, kPa
Temperature & pressure sensors: Yes, integrated in flow stream
Dimensions (H × W × D): 170 × 159 × 73.5 mm
Weight: 1.36 kg
Approximate time per reading: 1 – 15 seconds
Gas compatibility: Use with non-corrosive, non-condensing, non-combustible gases, humidity < 70%
Flow modes: Pressure or suction
Measurement cell style: Integrated
Reading modes: Single (manual), continuous or burst, with averaging function user-selectable from 1–100 measurements
Power supply / charger: 12 VDC, >250 mA, 2.5 mm center positive
Battery: 6V rechargeable sealed lead-acid, typical operation time 6–8 hours
Battery operational time (5 cycles/min): 3 hours (backlight on), 8 hours (backlight off)
Pressure and suction fittings: 1/4” ID Swagelok® fittings; 3/8” fittings for High model
Storage temperature: 0 – 70°C
Ambient humidity: 0 – 70% RH, non-condensing
Operating pressure (absolute): Atmospheric, 15 PSIA max
Display: Backlit graphical LCD
Data port (PC interface): USB
Data cable: 1 meter (FlexCal data port to PC serial port)
Protective case: Pelican case available
