Flow Range: 5–500 sL/min
Measurement Uncertainty: ±0.25% of reading
Weight: 90 lbs / 41 kg
Dimensions (H × W × D): 30” (W) × 34” (H) × 12” (D)
Data Cable: 1 meter, for use with data port
Data Port: RS-232 (serial), for PC interface
Display: Graphical LCD with backlight
Flow Measurement Cell: Integrated (all-in-one design; no additional flow models)
Flow Measurement Style: Single, Continuous or Burst, with averaging function user-selectable from 1 to 100
Flow Measurement Type: 2.38 lbs (1.08 kg)
Flow Mode: Pressure or suction
Gas Compatibility: Noncorrosive, noncondensing, noncombustible gases, less than 70% humidity
Humidity (Ambient): 0–70%, noncondensing
Inlet and Outlet Fittings: 1 1/2” Swagelok® compression tube fitting
Overpressure Release Fitting: 1/2” Swagelok® compression tube fitting
Storage Temperature: 0–70°C
Power: External power module
Input: 100–240 VAC, 1.6A (max), 50–60 Hz
Output: 12 VDC, 3.0A
Operating Pressure: 10–19.5 PSI (absolute)
Pressure Transducer: 0–20 PSI (absolute), accuracy ±0.05% FS (typical), ±0.10% (max)
Purge Fittings: 1/4” Swagelok® compression tube fittings
RoHS Compliant: Yes
Operating Temperature: 15–30°C
Valve Operation Air Supply: 80–100 PSI (not provided)
Valve Fitting: 1/4” Swagelok® compression
