Temperature: Set temperature range in °C min. 5°C above ambient up to +250°C
Temperature: 1 Pt100 sensor DIN class A in 4-wire-circuit
Language setting: German, English, Spanish, French, Polish, Czech, Hungarian
ControlCOCKPIT SingleDISPLAY. Adaptive multifunctional digital PID-microprocessor controller with high-definition TFT-colour display
Timer: Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
Function SetpointWAIT the process time does not start until the set temperature is reached
Calibration: three freely selectable temperature values
adjustable parameters temperature (Celsius or Fahrenheit), air flap position, programme time, time zones, summertime/wintertime
Convection : natural convection
Fresh air admixture: adjustment of pre-heated fresh air admixture by air flap control in 10 % steps
Vent: vent connection with restrictor flap
Documentation : programme stored in case of power failure
Programming : AtmoCONTROL software for reading out, managing and organising the data logger via Ethernet interface (temporary trial version can be downloaded). USB stick with AtmoCONTROL software available as accessory (on demand).
Temperature control: adjustable electronic overtemperature monitor and mechanical temperature limiter TB, protection class 1 according to DIN 12880 to switch off the heating approx. 20°C above nominal temperature
Autodiagnostic system: for fault analysis
Standard equipment
Internals: 1 stainless steel grid(s), electropolished
Works calibration certificate: Calibration at +160°C
Door : fully insulated stainless steel door with 2-point locking (compression door lock)
Stainless steel interior
Interior: easy-to-clean interior,made of stainless steel, reinforced by deep drawn ribbing with integrated and protected large-area heating on four sides
Volume : 32 l
Dimensions W x H x D in mm: w(A) x h(B) x d(C): 400 x 320 x 250 mm
Max. number of internals : 3
Max. loading of chamber : 60 kg
Max. loading per internal: 20 kg
Dimensions : w(D) x h(E) x d(F): 585 x 704 x 434 mm
Housing : rear zinc-plated steel
Electrical data
Voltage Electrical load: 230 V, 50/60 Hz
approx. 1600 W
Voltage Electrical load : 115 V, 50/60 Hz
approx. 1600 W
Set Up : The distance between the wall and the rear of the appliance must be at least 15 cm. The clearance from the ceiling must not be less than 20 cm and the side clearance from walls or nearby appliances must not be less than 5 cm.
Altitude of installation: max. 2,000 m above sea level
Ambient temperature: +5 °C to +40 °C
Humidity rh : max. 80 %, non-condensing
Overvoltage category: II
Pollution degree: 2
Transport information: The appliances must be transported upright
Customs tariff number: 8419 8998
Country of origin: Federal Republic of Germany
WEEE-Reg.-No.: DE 66812464
Dimensions approx incl. carton: B x H x T: 660 x 890 x 650 mm
Net weight: approx. 46 kg
Gross weight carton: approx. 62 kg
