Volume: approx. 241 liters
Interior dimension: width 600 x height 810 x depth 500 mm
Exterior dimension: width 759 x height 1180 x depth 691 mm
Stainless steel shelves: 2
Max. number of grids/shelves: 12
Fully insulated heated stainless steel door
Additional heated inner glass door
Entry port (silicon), 40 mm clear diameter, moisture tight, can be closed by silicone stopper, at the back, centre left
Door-open-recognition, incl. alarm, shuts down fan
Working temperature range: + 70C above ambient temperature up to 90°C
Setting temperature range: 18 – 90°C
Setting accuracy: 0.1°C
Capacitive humidity sensor for measuring and displaying the relative humidity
Active microprocessor control for humidifying 20 – 95 % rh, incl. digital indication and auto-diagnostic system ensures even more rapid reaching of set humidity and very short recovery times. Humidity supply with distilled water (from an external tank) by a selfpriming pump; integral bacteria block by generating hotsteam
Setting accuracy: 0.5% rh
Two high-resolution TFT colour displays with touch-sensitive buttons for selection of functions.
Adjustable parameters: temperature (Celsius or Fahrenheit), relative humidity, programme time, time zones
Two Pt100 sensors DIN class A in a 4-wire circuit for mutual monitoring, taking over functions in case of an error
HeatBALANCE function for application specific adjustment of heat output distribution (balance) between the upper and lower heating groups in an adjustment range between -50 % and +50 %.
AtmoCONTROL software on a USB stick for programming, managing and transferring programmes via Ethernet interface or USB port
ControlCOCKPIT with USB port for uploading programmes, reading out protocol logs, activating the User-ID function
Displaying of already logged protocol data on the ControlCOCKPIT (max 10,000 values correspond to approx. 1 week)
Ethernet interface on the rear of the appliance for reading out the protocol log and for uploading programmes and for online logging
Multiple overtemperature protection: Electronic temperature monitoring TWW/TWB (protection class 3.1 or 2 resp. 3.3 for units with active cooling) and mechanical temperature limiter TB (protection class 1) acc. to DIN 12880, AutoSAFETY automatically adjusts to the set value within a freely adjustable tolerance range. Setting individual MIN / MAX values for over/undertemperature alarm and also for all other parameters such as relative humidity
PID microprocessor control with integrated auto-diagnostic system
Structured stainless steel housing, scratch-resistant, robust and durable; rear of zinc-plated steel
Internal data logger with a storage capacity of at least 10 years
German, English, French, Spanish, Polish, Czech, Hungarian language settings available on the ControlCOCKPIT
Digital backwards counter with target time setting, adjustable from 1 minute to 99 days
Function setpointWAIT: the process time does not start until the set temperature is reached
Calibration: three freely selectable values each, temperature and humidity
Interface: Ethernet, USB
Programme stored in case of power failure
Integral fault diagnostics for temperature and humidity control
Alarm: visual and acoustic
6 sides heating: large-area multi-function heating system on four sides with additional door and back heating to avoid condensation
Door: fully insulated stainless steel door with 2-point locking, additional heated inner glass door.
Voltage: 230 V, 50/60 Hz
Electrical load: approx. 1840 W
Ambient temperature: 10 – 30°C
Humidity: max. 70% rh, non-condensing
Accessories:
+ Perforated stainless steel, 2 pcs
+ Work calibration certificate (measuring point chamber centre) at 60°C with 75% rh (Memmert supply)
+ USB storage medium with software and AtmoCONTROL manual
+ 1 water tank
+ Manual
