Voltage generators
Range
4-phase AC 4 x 300 V
4-channel DC 4 x 300 V
Power
4-phase AC 4 x 125 VA (max)
4-channel DC 4 x 125 W (max)
Inaccuracy AC
Typical 0.03% of reading + 0.01% of range
Guaranteed 0.05% of reading + 0.03% of range
Distortion(THD+N) 1) < 0.14% typical (0.25% max)
Resolution 10 mV
Phase
Angle range 0º - 360º
Inaccuracy 2) < 0.5º (at 50 and 60 Hz)
Resolution 0.1º
Frequency
Range 10 Hz - 600 Hz
Inaccuracy 2) <0.03 % (45 Hz - 66 Hz)
Resolution 1 mHz
Current generators
Range
3-phase AC 3 x 35 A
At least 15 repetitions: 10 s ON and 20
s OFF
3-phase DC 3 x 35 A
At least 15 repetitions: 10 s ON and 20
s OFF
3-phase AC 3 x 20 A continuous
3-phase DC 3 x 20 A continuous
Power
3-phase AC (max) 3 x 277 VA
3-phase DC (max) 3 x 275 W
Included accessories
Test cable set standard GA-00030
Earth (ground) cable GA-00200
Cable set 900 V GA-00036
Flight case with wheels GD-00185
Instrument configuration
Main Prefault - Fault
Ramping Sequencer CT Magnetization
Impedance
Prefault - Fault with MTT
Prefault - Fault
with MTT and
reference curves
