Mecmesin TTT-300B2 ເຄື່ອງທົດສອບແຮງບິດ (0.2-2 N.m, 0.002 N.m)
Measuring range: 0.2-2 N.m
Resolution: 0.002 N.m
Accuracy: ±0.5% of full-scale; Class 1 (DAkkS-DKD-R 3-8)
Display range: 120% of M(n)
Display type: LCD, 5-digit, 29 mm high
Interface:
USB: USB 2.0 data communication and supply
Hirose: Limit/overload signals, digital I/O's
Software: TTT_Certify software, Quick check or creation of calibration certificates
Supply type: Internal solar cell with storage capacitor / via USB
Temperature operation: 0-40°C
Dimension (L x W x H): 280 x 147 x 79 mm
Weight: 5 kg
Rating: IP42 (protection against falling dripping water)
Operating mode:
Standard: Display of current value
Peak (click + max): Peak value display (drag pointer function)
Quick check: Five follow-up measurements with averaging
Limit: Two separately selectable limits with upper and lower limit value
