Working Area: 380 × 540 mm
X, Y Axes Resolution: 5 µm (linear encoders as standard)
Dispensing Rate: Up to 10000 dots per hour
Vision System: Automatic fiducial correction, automatic bad mark recognition
Control Panel: 17" LCD monitor with keyboard and mouse
Options: Data import from CAD
Dimensions & Weight: 750 × 670 × 520 mm, 70 kg (140 kg including stand)
Power Supply: 230 V, 50 Hz, 200 W
Air Supply: 0.6 MPa, 20 l/min
Fully automated dispensing
Integrated vision system for Teach-in mode programming, automatic fiducial correction and bad mark recognition
Precise needle height adjustment
Built-in needle thermostat for reliable paste and liquids dispensing
Linear encoders for high accuracy and repeatability
Easy to use Microsoft Windows 10 based control system with third party CAD text files import capability for increased productivity
Excellent price to performance ratio and low TCO
