Voltage range: 0.00001V~120.000V
Voltage accuracy: 0.0002
Resistance Range: 0.0001mΩ~3.3000kΩ
Resistance Accuracy: 0.005
Communication interface: USB/232/485
Communication protocol: SCPI/MODBUS
ALARM IN: standard configuration
Test parameters: AC resistance, DC voltage
Display function: 4.3-inch touch LCD screen display, full touch operation
Basic accuracy: Resistance accuracy of 0.5%, voltage accuracy of 0.02% below 120V including 120V, 0.05% above 120V
Measurement range: Resistance test range: 0.0001mΩ~33000kΩ Voltage test range: 0.00001V~3000V
Signal source: 1kHz, frequency stability: 20ppm
Range: testing is used for measuring ranges of 3mΩ~3kΩ. The range is automatic, manual, and nominal. Range nominal: The instrument will automatically select the range based on the nominal value
Test speed:
+ The instrument has four speeds: slow, medium, fast, and high
+ Full channel open and manual range mode
+ Slow speed: 4 times/second Medium speed: 8 times/second
+ Fast: 20 times/second High speed: 55 times/second
Correct: short circuit reset within the full range
Comparator:
+ The instrument has sorting function
+ RHI/RNG/RLO outputs. VHI/VNG/VLO output. Total NG/OK output
+ Comparison method: Absolute value tolerance ±TOL
+ Sorting: Compare the absolute deviation between the measured value and the nominal value with the limits of each level
+ Percentage tolerance %TOL
+ Sorting: Compare the percentage deviation between the measured value and the nominal value with the limits of each level
+ Sequential comparison sorting: direct comparison of measured values with upper and lower limits
Trigger: internal trigger, manual trigger, external trigger, and remote trigger
Wire breakage detection function: wire breakage detection and open circuit detection
Interface: Handler interface RS-232/RS-485 interface USB interface
Power requirements: 85V-265VAC, 50/60Hz, power: 20VA
Attachment: Battery Internal Resistance Test Cable, RS232 Communication Cable
