MEAN WELL TKA30C-C ອິສເອລເທດ 25W 36-72Vin, +/-15V +/-25-+/-250mA, EMI

Width: 50.8 mm (2 in)

Height: 21 mm (0.827 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Dimensions: 50.8 mm x 50.8 mm x 21 mm

Unit Weight: 110 g

Output Power: 25 W

Input Voltage: 36 V to 72 V

Mounting Style: Through Hole

Isolation Voltage: 1 kV

Number of Outputs: 2 Output

Input Voltage - Max: 72 V

Input Voltage - Min: 36 V

Input Voltage, Nominal: 48 V

Output Current-Channel 1: 250 mA

Output Current-Channel 2: 250 mA

Output Current-Channel 3: - 250 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 15 V

Output Voltage-Channel 3: - 15 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
