MEAN WELL RPS-120S-48 ຕົວແປ AC-DC 120W 48V 2.5A 2x3 ທາງການແພດ

Width: 50.8 mm (2 in)

Height: 28 mm (1.102 in)

Length: 76.2 mm (3 in)

Industry: Medical, Industrial

Approvals: ANSI/AAMI ES60601-1, IEC/EN60601-1

Compliance: ANSI/AAMI ES60601-1, IEC/EN60601-1

Efficiency: 93.5 %

Unit Weight: 130 g

Output Power: 120 W

Input Voltage: 80 VAC to 264 VAC, 113 VDC to 370 VDC

Mounting Style: PCB

Input Frequency: 47 Hz to 63 Hz

Load Regulation: Regulated

Number of Outputs: 1 Output

Power - Convection: 120 W

Open Frame/Enclosed: Open Frame

Output Current-Channel 1: 2.5 A

Output Voltage-Channel 1: 48 VDC

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 30 C
