MEAN WELL QP-200F ເຊັດຊິ້ນສະພາບ 202.5W 5V/15A15V/3A 24V/3A -15V/0.7A

Width: 115 mm

Height: 50 mm

Length: 215 mm

Industry: Industrial

Approvals: EN60950-1, UL60950-1

Compliance: EN60950-1, UL60950-1

Unit Weight: 1.2 kg

Output Power: 202.5 W

Input Voltage: 90 VAC to 264 VAC, 127 VDC to 370 VDC

Mounting Style: Chassis

Input Frequency: 47 Hz to 63 Hz

Number of Outputs: 4 Output

Power - Convection: 202.5 W

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 15 A

Output Current-Channel 2: 3 A

Output Current-Channel 3: 3 A

Output Current-Channel 4: 700 mA

Output Voltage-Channel 1: 5 VDC

Output Voltage-Channel 2: 15 VDC

Output Voltage-Channel 3: 24 VDC

Output Voltage-Channel 4: - 15 VDC
