MEAN WELL MDR-100-24 ແຫຼ່ງພະລັງງານລົດໄຟ DIN (96W, 24V, 4A)
OUTPUT:
DC VOLTAGE: 24V
RATED CURRENT: 4A
CURRENT RANGE: 0 ~ 4A
RATED POWER: 96W
RIPPLE & NOISE (max.): 150mVp-p
VOLTAGE ADJ. RANGE: 24 ~ 30V
VOLTAGE TOLERANCE: ±1.0%
LINE REGULATION: ±1.0%
LOAD REGULATION: ±1.0%
SETUP, RISE TIME: 3000ms, 50ms/230VAC 3000ms, 50ms/115VAC at full load
HOLD UP TIME: 50ms/230VAC 20ms/115VAC at full load
INPUT
VOLTAGE RANGE: 85 ~ 264VAC, 120 ~ 370VDC
FREQUENCY RANGE: 47 ~ 63Hz
POWER FACTOR:
PF≧0.95/230VAC
PF≧0.98/115VAC at full load
EFFICIENCY: 86%
AC CURRENT: 1.3A/115VAC, 0.8A/230VAC
INRUSH CURRENT: COLD START 30A/115VAC 60A/230VAC
LEAKAGE CURRENT: <1mA / 240VAC
ENVIRONMENT:
WORKING TEMP.: -10 ~ +60℃ (Refer to "Derating Curve")
WORKING HUMIDITY: 20 ~ 90% RH non-condensing
