MEAN WELL LAD-240D ແຫຼ່ງພະລັງ AC/DC O/P +55.2V3.4A +55.2V1A

Width: 115 mm (4.528 in)

Height: 30 mm (1.181 in)

Length: 215 mm (8.465 in)

Industry: Industrial

Compliance: IEC62368-1, UL62368-1

Dimensions: 215 mm x 115 mm x 30 mm

Efficiency: 88 %

Unit Weight: 750 g

Output Power: 242.88 W

Input Voltage: 90 VAC to 132 VAC, 240 VDC to 370 VDC

Mounting Style: Chassis

Input Frequency: 47 Hz to 63 Hz

Load Regulation: Regulated

Number of Outputs: 2 Output

Open Frame/Enclosed: Enclosed

Output Current-Channel 1: 3.4 A

Output Current-Channel 2: 1 A

Output Voltage-Channel 1: 55.2 VDC

Output Voltage-Channel 2: 55.2 VDC

Maximum Operating Temperature: + 60 C

Minimum Operating Temperature: - 20 C
