MEAN WELL GD2-121503 ອິສເອລເທດ 2W 10.8-13.2Vin 15V/-3Vout +110mA/-100mA SIP7 Iso Unreg IGBT Sic Gate Driver

Width: 9.8 mm (0.386 in)

Height: 12.5 mm (0.492 in)

Length: 19.5 mm (0.768 in)

Dimensions: 19.5 mm x 9.8 mm x 12.5 mm

Unit Weight: 4 g

Output Power: 2 W

Input Voltage: 10.8 V to 13.2 V

Mounting Style: Through Hole

Number of Outputs: 2 Output

Input Voltage - Max: 13.2 V

Input Voltage - Min: 10.8 V

Input Voltage, Nominal: 12 V

Output Current-Channel 1: 110 mA

Output Current-Channel 2: 100 mA

Output Voltage-Channel 1: 15 V

Output Voltage-Channel 2: - 3 V

Maximum Operating Temperature: + 90 C

Minimum Operating Temperature: - 40 C
