MEAN WELL DKA15C-12 ອິສເອລເທດ 36-72Vin +/-12Vout 62.5-625mA, 15W

Width: 25.4 mm (1 in)

Height: 11.27 mm (0.444 in)

Length: 50.8 mm (2 in)

Industry: Industrial

Dimensions: 50.8 mm x 25.4 mm x 11.27 mm

Efficiency: 82 %

Unit Weight: 32 g

Output Power: 15 W

Input Voltage: 36 V to 72 V

Cooling Method: Convection

Mounting Style: Through Hole

Mechanical Style: Isolated

Isolation Voltage: 1 kV

Number of Outputs: 2 Output

Input Voltage - Max: 72 V

Input Voltage - Min: 36 V

Output Current-Channel 1: 625 mA

Output Current-Channel 2: 625 mA

Output Voltage-Channel 1: 12 V

Output Voltage-Channel 2: - 12 V

Maximum Operating Temperature: + 71 C

Minimum Operating Temperature: - 40 C
