MEAN WELL DETN01L-05N ອິສເອລເທດ 1W, I/P:5VDC; O/P:5V @100mA

Width: 10.9 mm

Height: 9.1 mm

Length: 15.24 mm

Industry: Industrial

Dimensions: 15.24 mm x 10.9 mm x 9.1 mm

Application: Analyser, Detector

Unit Weight: 1.200 g

Output Power: 1 W

Input Voltage: 4.5 V to 5.5 V

Mounting Style: SMD/SMT

Isolation Voltage: 3 kV

Number of Outputs: 2 Output

Input Voltage - Max: 5.5 V

Input Voltage - Min: 4.5 V

Input Voltage, Nominal: 5 V

Output Current-Channel 1: 10 mA to 100 mA

Output Current-Channel 2: 10 mA to 100 mA

Output Voltage-Channel 1: 5 V

Output Voltage-Channel 2: - 5 V

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 40 C
