MaxLinear SP3078EEN-L/TR ຕົວສົ່ງຮັບ RS485/RS422 Driver/ Receiver Transceiver

Duplex: Half Duplex

Function: Transceiver

Shutdown: Shutdown

Data Rate: 16 Mb/s

Output Type: Differential

Unit Weight: 143 mg

Input Voltage: - 7 V to 12 V

ESD Protection: +/-15 kV

Mounting Style: SMD/SMT

Output Current: 250 mA

Output Voltage: 1.5 V to 3.3 V

Number of Drivers: 1 Driver

Protocol Supported: RS-422, RS-485

Number of Receivers: 1 Receiver

Supply Voltage - Max: 3.6 V

Supply Voltage - Min: 3 V

Pd - Power Dissipation: 471 mW

Propagation Delay Time: 50 ns, 75 ns

Operating Supply Current: 800 uA

Operating Supply Voltage: 3.3 V

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
