Gain V/V: 5 V/V
Shutdown: Shutdown
Output Type: Rail-to-Rail
3 dB Bandwidth: 42 MHz
Amplifier Type: Low Noise, Low Bias
Mounting Style: SMD/SMT
SR - Slew Rate: 10 V/us
THD plus Noise: - 110 dB
Development Kit: MAX40088EVKIT#
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V, +/- 2.75 V
Supply Voltage - Min: 2.7 V, +/- 1.35 V
Ib - Input Bias Current: 2.3 nA
Operating Supply Current: 2.5 mA
Ios - Input Offset Current: 500 pA
Output Current per Channel: 48 mA
Vos - Input Offset Voltage: 150 uV
Maximum Dual Supply Voltage: +/- 2.75 V
Minimum Dual Supply Voltage: +/- 1.35 V
GBP - Gain Bandwidth Product: 42 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 40 C
In - Input Noise Current Density: 0.5 fA/sqrt Hz
en - Input Voltage Noise Density: 5.5 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 109 dB
PSRR - Power Supply Rejection Ratio: 107 dB
