Rated input voltage: AC220V/110V ±10%
Rated output voltage: 0~80V
Rated output current: 0~20A
Rated output power: 400W
Load regulation rate: Voltage ≤ 0.01% + 30mV, Current ≤ 0.05% + 6mA
Line regulation: Voltage ≤ 0.01% + 30mV, Current ≤ 0.05% + 6mA
Setting value resolution: Voltage 1mV, Current 1mA
Readback value resolution: Voltage 1mV, Current 1mA
Setting accuracy (25°C ± 5°C): Voltage ≤ 0.03% + 5mV, Current ≤ 0.1% + 10mA
Readback accuracy (25°C ± 5°C): Voltage ≤ 0.03% + 5mV, Current ≤ 0.1% + 10mA
Ripple: Voltage ≤ 8 mVms, Current ≤ 8mArms
Rising time: ≤ 150mS (10% ~ 90%)
Falling time: ≤ 2S (10% ~ 90%)
Size (mm): 255 * 110 * 475
Weight (kg): 13.3
Datasheet
Catalog
LIST output function
Timing output time can be set (0.1~99999.9 seconds)
Remote compensation function to compensate the voltage drop on line
With abundant SCPI instructions make it easy to build an intelligent testing platform
Optional external analog control function
Supports output from the front and rear panels
DVM voltmeter measurement function
Internal temperature monitoring function
