MATRIX WPS200-8010L ການສະຫນອງພະລັງງານ DC ຊ່ອງດຽວ (80V, 10A, 200W)

Rated input voltage: AC220V/110V ±10%

Rated output voltage: 0~80V

Rated output current: 0~10A

Rated output power: 200W

Load regulation rate: Voltage ≤ 0.01% + 10mV, Current ≤ 0.05% + 4mA

Line regulation: Voltage ≤ 0.01% + 10mV, Current ≤ 0.05% + 4mA

Setting value resolution: Voltage 1mV, Current 1mA

Readback value resolution: Voltage 1mV, Current 1mA

Setting accuracy (25°C ± 5°C): Voltage ≤ 0.03% + 5mV, Current ≤ 0.1% + 5mA

Readback accuracy (25°C ± 5°C): Voltage ≤ 0.03% + 5mV, Current ≤ 0.1% + 5mA

Ripple: Voltage ≤ 5 mVms, Current ≤ 6mArms

Rising time: ≤ 150mS (10% ~ 90%)

Falling time: ≤ 2S (10% ~ 90%)

Size (mm): 255 * 110 * 380

Weight (kg): 9.2

Datasheet

Catalog

Features

LIST output function

Timing output time can be set (0.1~99999.9 seconds)

Remote compensation function to compensate the voltage drop on line

With abundant SCPI instructions make it easy to build an intelligent testing platform

Optional external analog control function

Supports output from the front and rear panels

DVM voltmeter measurement function

Internal temperature monitoring function
