Voltage: 0-40V
Current: 0-60A
Power: 1500W
Ripple: 10mVrms
Rated input: Single phase 220VAC±10% 45-66Hz
DC output:
Output voltage: 0V-rated value
Output current: 0A-rated value
Output power: 0W-rated value
Efficiency: ≤92%
Setting value accuracy:
Voltage: ≤ ±(0.05% + 0.04% FS)
Current: ≤ ±(0.15% + 0.1% FS)
Power: ≤ ±0.8% FS
Readback value accuracy:
Voltage: ≤ ±(0.05% + 0.04%FS)
Current: ≤ ±(0.15% + 0.1%FS)
Power: ≤ ±0.8% FS
Source effect:
Voltage: ≤ 0.02% FS (± 10% UAC input)
Current: ≤ 0.05% FS (± 10% UAC input)
Load effect:
Voltage: ≤ 0.05% FS (0-100% load adjustment rate)
Current: 0.15% FS (load adjustment rate of 0-100% △UDC)
Specitications: Built in 15-pin D-Sub female plug, electrically isolated
Analog interface:
Signal range: 0~5V or 0~10V (switchable)
U/I/P accuracy: 0 -10V: ≤ 0.2% FS 0 -5V: ≤0.4%FS
Dynamic response time(10%-90% load):
Load adjustment time: ≤2ms (load adjusted from 10 to 100%)
Output voltage rise time: 30ms
Functional protection: OTP, OVP, OCP, OPP, PF
Interface: RS232/ RS485/ USB/ LAN and other communication interfaces
Parallel operation: Realizable, can connect up to 10 products (via shared bus) through real master-slave operation
Operating environment: Working temperature: 0-50 °C, humidity: <80%, storage temperature: -20~70 °C, altitude: <2000m
Weight: 10.8kg
Size: 482*455*88mm
