Voltage: 0~60V
Current: 0~15A
Power: 900W
Rated input voltage: AC220V/110V±10%
Transformer mode: Switch power supply
Voltage regulation rate: Voltage <= 0.1% + 20mV, Current ≤0.1%+5mA
Load regulation rate: Voltage <= 0.1% + 20mV, Current ≤0.1%+5mA
Power regulation rate: Voltage ≤0.1% + 20mV, Current ≤0.1%+5mA
Setting resolution: Voltage 1mV, Current 1mA
Setting accuracy: Voltage ≤0.1% + 10mV, Current ≤0.3%+8mA
Readback resolution: Voltage 1mV, Current 1mA
Readback accuracy: Voltage ≤0.1% + 10mV, Current ≤0.3%+8mA
Operating temperature: 0 to 40°C ≤85% R.H.
Storage temperature: -15 to 70°C ≤85% R.H.
Product size (WxHxD): 230x105x330 mm
Net weight: 3.5kg
Gross weight: 4.5kg
Datasheet
Catalog
Features
• Set voltage and current in two ways: digital keyboard and knob
• Voltage 1mV and current 1mA resolution, high precision display
• Multiple group voltage and current storage call function
• Battery charging mode, the upper and lower limits of thecurrent setting function, with an alarm
• The appearance is fashionable and small, afford- able, cost-effective ultra-high
Applications
■Experimental technique
■Electronic maintenance
■Aging test
■DIY
