Rated input voltage: AC220V±10%
Rated DC output (0°C40°C):
Voltage: 0~60V
Current: 0~10A
Power: 600W
OVP: 0.1~64V
OCP: 0.1~12A
Power effect: Voltage ≤0.01%+10mV, Current ≤0.2%+10mA
Load effect: Voltage ≤0.1%+5mV, Current ≤0.2%+5mA
Setting precision: Voltage ±(0.03% of reading+10mV) (25±5°C), Current ±(0.3% of reading+10mA) (25±5°C)
Setting resolution: 1mV/1mA
Voltage recovery time: ≤1.5ms (50% load change)
Voltage temperature coefficient: ≤300ppm/°C
Accuracy of reading: Voltage ±(0.02% of reading+5mV) (25±5°C), Current ±(0.05% of reading+10mA) (25±5°C)
Protection: OLP, OVP, OCP, OTP, RP
Interface: Standard RS-232, supports SCPI instruction set, analog control interface (optional)
Storage redeployment: 100 groups
Operating environment: Indoor use, altitude ≤2000m, ambient temperature 0~40°C, relative humidity ≤80%, install level II, degree of pollution 2
Storage environment: Ambient temperature -10~70°C, relative humidity ≤70%
Power input: AC 220V±10%, 50/60Hz
Accessories: User manual 1pc, power cord1pc
Instrument size (WxHxD): 220x150x400 mm
Net weight: 4.6kg
Datasheet
Catalog
• Voltage 1mV current 1mA resolution, high precision display
• Set voltage and current in two ways; digital keyboard and knob
• 100 sets of voltage and current storage call out function, convenient and quick
• Voltage compensation function ensures high precision
Output switch control, easy to control
• Intelligent temperature control fan, extremely practical
• The knob adopts the code switch, which is convenient to use and has the function of preventing misadjustment
• Over voltage, over current, over temperature protection function
