Rated input voltage: AC220V/110V ± 10%
Rated output voltage: 0-62V
Rated output current: 0-5A
Rated output power: 310W
Load regulation: Voltage: <0.1% + 5mV, Current: <0.2% + 3mA
Line regulation: Voltage: <0.01% + 5mV, Current: <0.2% + 3mA
Setting accuracy: Voltage: ≤0.1% + 2 digit, Current: ≤0.2% + 3mA
Setting resolution: Voltage: 10mV, Current: 1mA
Readback accuracy: Voltage: ≤0.1% + 2 digit, Current: ≤0.2% + 3mA
Readback resolution: Voltage: 10mV, Current: 1mA
Ripple: Voltage: ≤10mVrms, Current: ≤5mArms
OVP: 0-62V ± 0.2% FS
Maximum voltage: 62V ± 0.2%
OCP: 0-5.1A ± 0.2% FS
Maximum current: 5.1A ± 0.2%
Operating environment: 0 ~ 40°C ≤ 80RH
Storage environment: -15 ~ 70°C ≤ 80RH
Instrument size (WxHxD): 115x96x261 mm
Net weight: 1.5 kg
Gross weight: 1.9 kg
Datasheet
Catalog
• Voltage and current simultaneously display, double four-digit LED display
• High power up to 320W with small volume
• Smart fan, unique air duct design keeps normal temperature for long time full load working
• Five sets of storage functions, greatly conve- nient for users
• OVP/OCP setting function
• Encoder sets voltage and current
• Fast and longer life
• Output control function
