MATRIX MPS-3010H-3 ການສະຫນອງພະລັງງານ DC Linear Triple-channel ຄວາມແມ່ນຍໍາສູງ (30V, 10A, 3 channels)
Rated output:
Voltage: 0-30V (CH1, CH2), 5V (CH3)
Current: 0-10A (CH1, CH2), 3A (CH3)
Load regulation:
Voltage: ≤0.01%+8mV (CH1, CH2), ≤15mV (CH3)
Current: ≤0.1%+5mA (CH1, CH2)
Power regulation
Voltage: ≤0.01%+8mV (CH1, CH2)
Current: ≤0.1%+5mA (CH1, CH2)
Set resolution:
Voltage: 10mV (CH1, CH2)
Current: 1mA (CH1, CH2)
Readback resolution:
Voltage: 10mV (CH1, CH2)
Current: 1mA (CH1, CH2)
Set value accuracy:
Voltage: ≤0.03%+10mV (CH1, CH2)
Current: ≤0.1%+5mA (CH1, CH2)
Readback accuracy:
Voltage: ≤0.03%+10mV (CH1, CH2)
Current: ≤0.1%+5mA (CH1, CH2)
Parallel mode:
Power effect: ≤0.02%+8mV (CH1, CH2)
Load effect: ≤0.02%+8mV (CH1, CH2)
Serial mode:
Power effect: ≤0.01%+8mV (CH1, CH2)
Load effect: ≤0.01%+8mV (CH1, CH2)
Ripple and noise:
Voltage: ≤2mV(rms) (CH1, CH2, CH3)
Current: ≤5mA(rms) (CH1, CH2, CH3)
Working temperature: 0~40°C, ≤80%RH
Size (mm): 250*150*330
Weight (kg): 12
