MATRIX MPS-1510D+ ການສະຫນອງພະລັງງານ DC ຊ່ອງດຽວ (15V, 10A, 150W)

Rated input voltage: AC220V/110V±10%

Rated output voltage: 0-15V

Rated output current: 0-10A

Rated output power: 150W

Load regulation rate: Voltage < 0.02% + 10mV, Current <0.2%±1digits

Line regulation: Voltage < 0.02% + 10mV, Current <0.2%±1digits

Display resolution: Voltage 100mV Current < 10A / 10 * mA 10A:100mA

Display accuracy:  <= 0.2% + 2 digits (Environment temperature: 23°C ± 5°C )

Ripple: Voltage ≤2mVrms, Current 10mArms

Temperature Coefficient: 300ppm/°C

Max. output voltage: 15.5V plus/minus 0.5 V

Max. output current: 10.1A plus/minus 0.05 A

Input voltage: AC 220V / (110V plus/minus 10)% 50Hz/60Hz

Working condition: Temperature 0°C ~40°C,  Relative humidity < 80%

Storage condition: Temperature -15°C ~70°C, Relative humidity < 80%

Cooling method: Smart air cooling

Size (mm): 280  * 130 * 160

Net weight kg: 5.7

Gross weight kg: 6.4

Datasheet

Catalog

• Current pre-set without short circuit, namly can set the max output current directly

• Smart fan reduce the working noise

• Spec:30V/3A, 30V/5A, 60V/3A, 30V/10A, 60V/5A, 15V/10A, 15V/15A

• OTP over temperature protection, more comprehensive protection; • Output on/off function

• Fine/coarse tuning

• Input voltage 110V/220V switchable

• The smallest 300W(60V/5A,30V/10A) linear adjustable power supply in industry
