Bandwidth: Up to 250MHz
Sample Rate: 1GS/s
Horizontal Scale (s/div): 2ns/div - 1000s/div, step by 1-2-5
Rise Time (at input, typical): ≤1.7ns
Channel: 2
Display: 7" color LCD, 800 x 480 pixels
Input Impedance: 1ΜΩ ± 2%, in parallel with 20pF ± 5pF
Channel Isolation: 50Hz: 100:1, 10MHz: 40:1
Maximum Input Voltage: 400V (PK-PK) (DC+AC, PK-PK)
DC Gain Accuracy: ±3%
Record Length: 10K
DC Accuracy (average): Average ≥ 16: ±(3% reading + 0.05 div) for ∆V
Probe Attenuation Factor: 1X, 10X, 100X, 1000X
LF Respond (AC, -3dB): ≥10Hz (at input, AC coupling, -3dB)
Sample Rate / Relay Time Accuracy: ±100ppm
Interpolation: sin (x) / x
Interval (∆T) Accuracy (full bandwidth): Single: ±(1 interval time + 100ppm x reading + 0.6ns), Average >16: ±(1 interval time + 100ppm x reading + 0.4ns)
Input Coupling: DC, AC, and GND
Vertical Resolution (A/D): 8 bits (2 channels simultaneously)
Vertical Sensitivity: 5mV/div - 5V/div (at input)
Trigger Type: Edge, Video
Trigger Mode: Auto, Normal, and Single
Trigger Level: ±5 divisions from screen center
Line / Field Frequency (video): NTSC, PAL, and SECAM standard
Cursor Measurement: ∆V, and ∆T between cursors
Automatic Measurement: Vpp, Vavg, RMS, Frequency, Period, Vmax, Vmin, Vtop, Vbase, Width, Overshoot, Pre-shoot, Rise time, Fall time, +Width, Width, +Duty, -Duty, Delay A→B, Delay A-B, area, cycle area
Waveform Math: +, -, x, ÷, invert, FFT
Waveform Storage: 16 waveforms
Lissajous Figure: Full bandwidth ±3 degrees
Communication Interface: USB host, USB device available
Frequency Counter: Full bandwidth ±3 degrees
Power Supply: 100V-240V AC, 50/60Hz, CAT II
Power Consumption: <15W
Fuse: 2A, T class, 250V
Dimensions (W x H x D): 301 x 152 x 70 mm
Device Weight: 1.10 kg
