Test parameters: L, C, R, lZl, R, X, ESR, θ (Deg), θ (Rad)
Test frequency: 100Hz, 120Hz, 1kHz, 10kHz, 20kHz, 30kHz
Basic measurement accuracy: 0.1%
Test signal level: 0.1V, 0.3V, 1V
Equivalent Circuit: Series Parallel
Mathematical functions: Percentage deviation
Range method: Automatic, hold, manual selection
Trigger method: Internal, manual, external, bus
Measuring speed (≥1kHz): Fast: the fastest 30 times / second, medium speed: 10 times / second. Slow speed: 3 times / second
Average times: 1-255
Delay time: 0-6S, step by 1ms
Calibration function: Open circuit / short circuit / quick reset
Display method: Direct reading, Δ%, V / I (measured voltage / current monitoring)
Monitor: 5-digit display of main and auxiliary parameters, 4.3-inch true color LCD display
Output impedance: 30Ω, 100Ω optional
Comparator function: 5 files sorting function
Memory: More than 100 sets of internal instrument settings for storage / recall, U disk expands more than 500 sets
interface: Standard RS-232C, HANDLER, USB HOST, optional USB DEVICE, headphone jack, foot pedal, GPIB
Bare metal size (W * H * D): 240 * 100 * 330mm
Packing size (W * H * D): 330 * 210 * 425mm
N.W (kg): 3.8
G.W (kg): 4.7
