Capacity: 2KVA
Operating mode: SPWM
Input:
Phase: 1φ2W
Voltage: 220V ± 10%
Frequency: 45-63Hz
Output:
Phase: 1Φ2W
Voltage: 0~155VAC / 0~310VAC AUTO 0~600V optional
Frequency: 45~500Hz (0.01step)
Maximum current:
L = 120V: 16.8A
H = 240V: 8.4A
Load regulation: 1%
Waveform distortion: 2% (low-end 120V, high-end 240V, with pure resistive load)
Frequency stability: 0.01%
Display: Voltage / current / Frequency / power / power factor
Voltage resolution: 0.01V
Frequency resolution: 0.01Hz
Current resolution: 0.001A
Storage: M1~M3 (V_F_A)
Test accuracy:
Voltage: ± 0.5% FS + 5dgt
Electric current: ± 0.5% FS + 5dgt
Frequency: ± 0.01% FS + 5dgt
Power: ± 0.5% FS + 5dgt
Setting accuracy:
Voltage: ± 1% FS
Frequency: ± 0.1% FS
Communication Interface: Standard RS232, optional RS485
Current limit setting: 0~Max Current (The maximum current is: maximum capacity / 240V or P / 240)
Output protection: Overcurrent, overtemperature, overload, short circuit
Operating environment: 0~40 °C ≤80% RH
Bare metal size (mm): 480 * 225 * 535
Net weight (kg): 30.5
