Marktech Optoelectronics MT6224B-AHRG-A ໄຟ LED ຫຼາຍສີ 568nm 5mm ເລນສກົງພລາສຕິກ

Width: 5.9 mm

Height: 8.7 mm

Length: 5.9 mm

LED Size: T-1 3/4 (5 mm)

Lens Color: Colorless

Lens Shape: Dome

Power Rating: 72 mW

Configuration: Common Anode

Viewing Angle: 70 deg

Mounting Style: Through Hole

Lens Dimensions: 5 mm

Peak Wavelength: 650 nm, 573 nm

Lens Transparency: Diffused

Illumination Color: Red, Yellow-Green

Luminous Intensity: 20 mcd

Moisture Sensitive: Yes

If - Forward Current: 20 mA

Vf - Forward Voltage: 1.9 V

Wavelength/Color Temperature: 639 nm, 570 nm

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 25 C
