HiTemp140
Temperature
Temperature Sensor: 100 Ω Platinum RTD
Temperature Resolution: 0.01°C (0.02°F)
Calibrated Accuracy
± 0.1°C / ± 0.18°F (20°C to 140°C / 68°F to 284°F)
± 0.3°C / ± 0.54°F (-20°C to 19.99°C / -4°F to 67.98°F)
± 0.4°C / ± 0.72°F (-40°C to -20.01°C / -40°F to -4.02°F)
Probe Temperature Range: -200°C ~ 260°C (-328°F ~ 500°F)
General
Memory: 32,700 Readings
Reading Rate: 1 reading every 1 s up to 1 reading every 24 hrs
Baud Rate: 125,000
Wrap-Around: Yes
Start Modes:
Software programmable immediate start
Delay start up to 18 months in advance
Stop Modes: Manual or Timed (specific date and time)
Real-Time Recording: May be used with PC to monitor and record data in real-time
Password Protection:
An optional password may be programmed into the device to restrict access and configuration options.
Data may be read without the password
Battery Type: 3.6 V high-temperature lithium battery (included), user-replaceable
Battery Life: 1 year typical at 1 min reading rate at 25°C (77°F)
Material: 316 Stainless Steel
Weight: 4.2 oz (120 g)
Dimensions (Probe)
HiTemp140-1
1.1 in x 0.125 in dia. (0.188 in transitional dia.)
27 mm x 3.2 mm dia. (4.8 mm transitional dia.)
HiTemp140-2: 2.0 in x 0.188 in dia. (51 mm x 4.8 mm)
HiTemp140-2-TD
2.0 in x 0.125 in dia. (0.188 in transitional dia.)
51 mm x 3.2 mm dia. (4.8 mm transitional dia.)
HiTemp140-5.25: 5.25 in x 0.188 in dia. (133 mm x 4.8 mm dia.)
HiTemp140-5.25-TD
5.25 in x 0.125 in dia. (0.188 in transitional dia.)
133 mm x 3.2 mm dia. (4.8 mm transitional dia.)
HiTemp140-7: 7.0 in x 0.188 in dia. (178 mm x 4.8 mm dia.)
Dimensions (Body)
HiTemp140-1: 1.6 in x 0.970 in dia. (40 mm x 24.6 mm dia.)
HiTemp140-2, 5.25, 7: 1.9 in x 0.970 in dia. (48 mm x 24.6 mm dia.)
IP Rating: IP68
Submersible: Yes
Operating Environment: -40°C - 140°C (-40°F - 284 °F), 0% RH - 100% RH, Non-condensing
Required Interface Package: IFC400
Approvals: CE
Kit Specifications
Operating Environment: -200°C - 250°C (-328°F - 482°F) (time limited), 0% RH - 100% RH
Dimensions
Flush Top: 2.75 in x 2.0 in dia.(69.85 mm x 51 mm dia.)
Vented Top: 4.3 in x 2.0 in dia.(109.2 mm x 50.8 mm dia.)
Material (Enclosure): PTFE
Weight (Not Including Data Logger)
Flush: 6.7 oz (190 g)
Vented: 9.5 oz (270 g)
PR140
Pressure
Pressure Sensor: Semiconductor Strain Gauge
Pressure Range: 0 bar - 5 bar (0 PSIA - 72.5 PSIA)
Pressure Resolution: 0.0001 bar (0.0015 PSIA)
Pressure Calibrated Accuracy
± 0.03 bar (± 0.435 PSI)
+20°C - 140°C (68°F - 284°F)
Pressure Response Time: 0.1 ms (10% - 90% FSR)
General
Memory: 32,700 readings; software configurable memory wrap
Reading Rate: 1 s to once every 24 hours, selectable in software
Baud Rate: 125,000
Start Modes: Software programmable immediate start or delay start up to six (6) months
Real-Time Recording: May be used with PC to monitor and record data in real time
Calibration: Digital calibration through software
Calibration Interval: Yearly calibration recommended
Calibration Date: Automatically recorded within device
Battery Type: 3.6 V high-temperature lithium battery included, user replaceable
Battery Life: 2 years typical, 1 min reading rate at 25°C (77°F)
Data Format: PSIG, inHg, mmHg, bar, atm, Torr, Pa, kPa, MPa
Time Accuracy: ± 1 min/month (at 20°C - 30°C)
Computer Interface: USB (interface cable required); 115,200 baud
Software: XP SP3/Vista/Windows 7/Windows 8
Material: Stainless Steel
Dimensions
Flush Top: 2.0 in x 1.0 in dia. (50.8 mm x 25.4 mm dia.)
NPT Pressure Port Top: 2.29 in x 1.0 in dia. (58.2 mm x 25.4 mm dia.)
IP Rating: IP68
Submersible: Yes
Operating Environment: -20°C - 140°C (-4°F - 284°F), 0% RH - 100% RH
Note: The PR140 may be used above 60°C for up to 8 hrs, per 24 hr period.
Approvals: CE
