Mackma CEBORA 3035/M Plasma Sound Cebora

Single phase input: 230V / 50/60 Hz / ± 10%

115 V / 50/60 Hz / + 15% / -20%

Fuse rating (slow blow): 32 A/16 A

Input power: 3.5 kVA 40%

2,8 kVA 60%

2.4 kVA 100%

Current adjustment range: 5 A ÷ 30 A

Duty Cycle (10 min.40°C) According to IEC 60974-1: 30 A 35%

25 A 60%

22 A 100%

Stepless regulation: Electronic

Thickness on steel: Recommended – Max – (Severance): 8 – 12 -(15) mm

1/3” – 1/2" – (5/8”)

Air consumption: 60 l/min @ 3,5 bar

Protection class: IP23S

Weight: 13 Kg

Dimensions (WxLxH): 175x503x400 mm
