Lumex SML-LXT0805SIUGUBW ໄຟ LED ຫຼາຍສີ SMT 1.25mm X 2.00mm 632nmR,468nmG,468nmB

Width: 1.3 mm

Height: 0.5 mm

Length: 2 mm

Lens Color: Colorless

Lens Shape: Rectangular

Unit Weight: 82 mg

Power Rating: 72 mW, 78 mW, 78 mW

Viewing Angle: 140 deg

Mounting Style: SMD/SMT

Lens Dimensions: 1.4 mm x 1.3 mm

Lens Transparency: Diffused

Illumination Color: RGB

Luminous Intensity: 285 mcd, 360 mcd, 180 mcd

Moisture Sensitive: Yes

If - Forward Current: 20 mA

Vf - Forward Voltage: 2.4 V, 3.9 V, 3.9 V

Vr - Reverse Voltage: 5 V

Wavelength/Color Temperature: 632 nm, 520 nm, 468 nm

Maximum Operating Temperature: + 80 C

Minimum Operating Temperature: - 30 C
