Motor rating: 0.2kW/0.25HP
Capacity Output rating: 0.6 (kVA)
Current Output rating: 1.4(A)
Voltage Output rating: 3P 200 ~ 230V(V)
Frequency Output rating: 0.1 ~ 200(Hz)
Input Rating: 1P 220V ~ 230V /50-60Hz/3.5A
Control method: V/F
Speed reference resolution: Digital: 0.01Hz / Analog: 0.1 Hz
Frequency accuracy: Digital: 0.01% / Analog: 0.1%
Overload Capacity: 150% for 1 minute
Torque Boost: Auto & manual torque boost
Display: 4 digit, 7 segment LED
Operation method: Keypad/ terminal/ communication
Frequency setting: Analog: 0-10V/0-20mA/ keypad
Operation function: PI control/ Up-down/ 3-Wire
Input signal: PNP/NPN selectable/ P1 ~ P5
Output Signal: NO/NC, 0-10V, Frequency/ Current
Protection: Over voltage/ Low voltage/ Over current/ Ground fault/ Inverter overload/ Inverter overheat/ Output phase open/ Hardware fault ....
Enclosure: IP20
DC Injection braking
Communication( Option): RS485 ( LS Bus/ Modbus RTU)
Weight: 0.46 kg
Dimension: 68 x 128 x 85 mm
