Application:
It is the most important testing instrument for the development of new products, the research of the formulation of rubber materials, the control of the quality of rubber materials and the application of rubber basic research. It is widely used in all kinds of rubber products.
Specification:
Temperature range control: RT—200℃
Temperature fluctuation range: ±0.15℃
Torque resolution: 1/500000
Torque accuracy: 0.3%
Torque unit: N.m, N.cm, N.inch, kN.m, kN.cm, kN.inch, kg.m, kg.cm, kg.inch, lp.m, lp.cm, lp.inch, g.m, g.cm, g.inch
Temperature display réolution: 0.01℃
Temperature recovery time after mold closing: < 1.5min
Temperature unit: C(degree centigrade ) , F(Fahrenheit) , K
(Kelvin)
Sampling rate: 200times/S
Support language: English, simplified Chinese, traditional Chinese
Test standard: GB/T 16584, ASTM D5289, ISO 6502
Calculating parameter: ts1, ts2, t10, t30, t50, t70, t90, Vc1, Vc2
Software connector: USB2.0
Print date: Date, time, temperature, cure curve, temperature curve, ML, MH, ts1, ts2, t10, t50, t90, Vc1, Vc2
Test standard: ASTM D 5289, ISO6502
Oscillation frequency: 100 cycles per minute(1.67Hz)
Amplitude of oscillation: standard configuration： ±1degree ±0.03degree/ (optional)±0.5degree±0.03degree, ±3degree±0.03degree
Variable temperature time:
170℃→190℃ within 55s ±0.3℃
190℃→170℃ with 1minute 40s ±0.3℃
Temperature return time after membrane closure: temperature compensation is restored to the set temperature of 170℃(error±0.3℃) not big than 30±3s
Heating speed: RT→170℃ 2 minutes 40s ±0.3℃
Power: 220VAC±10%, 50±3Hz；
Air source: Min minimum 65psi (4.5kg/cm2)
Size: L65cm x W59cmx H148cm
Weight Gross: 300kg , Net: 250kg
