Range of application
1. Black metal, non-ferrous metal, IC flake, surface coating, laminated metal;
2. Glass, ceramics, agate, precious stones, thin plastic, etc.;
3. Depth and gradient hardness test of carbonization layer and quenching layer.
Main technical parameters
1. Measurement range: 5-5000hv.
2. Test force: (level 8)
1.961N (0.2kgf) 2.942n (0.3 KGF) 4.903N (0.5 KGF) 9.807N (1.0 KGF) 19.61N (2.0 KGF) 24.52N (2.5 KGF) 29.42N (3.0 KGF) 49.03N (5.0 KGF)
3. Optical measurement system.
Objective: 10 x, 40 x.
Total magnification: 100 x, 400 x.
Measurement range: 200 mu m.
Dividing value: 0.025 mu m.
4. Appearance size and power supply.
Dimensions: 600*330*700mm;
Maximum height: 200mm;
Pressure head center to machine wall distance: 130mm;
Power supply: AC220V/50Hz;
Weight: 70Kg.
