Applications
Determine Brinell hardness of ferrous metal, non-ferrous metal and bearing alloy materials;
Hard cast steel, aluminum alloy, copper alloy, malleable castings, mild steel, tempered steel, annealed steel, bearing steel, etc.
Technical Parameters:
Range of measurement: 5-650HBW
Force of test: 612.9, 980.7, 1225.9, 1838.8, 2451.8, 4903.5, 7355.3, 9807, 14710.5, 29421N (62.5, 100, 125, 187.5, 250, 500, 750, 1000, 1500, 3000kgf)
Mode of loading: overlapping gate ccd
Turret mode: Hand turret
Method of testing: Automatic surveying and mapping
The maximum allowable height of the specimen: 280mm
Distance from indenter center to machine wall: 165mm
Magnification of lens: 1X
Total magnification: 20X
Resolution of hardness: 0.1HBW
Minimum step length: 0.625μm
Power supply: AC 220V, 50Hz
Overall dimensions: 700*268*930mm
Weight: 210kg
